CATL LFP 3.2V 150ah LiFePO4 Battery Prismatic Cell for RV/Solar System/Yacht/Golf Carts
1. Strict Quality Pursuit: The cell’s QR code is intact, Grade A, and 100% Brand new.Professional lithium battery manufacturer with more than 10 years of experience, excellent customer service and technical support, strict quality control system, and professional R&D department.
2. CATL 150Ah Prismatic LiFePO4 Battery Cells' Voltage and Internal resistance will be tested before packaging. All are balanced with high consistency.
3. Safety And Environmental Protection: made of 100% safe, non-toxic, renewable energy, CATL 150Ah Prismatic LiFePO4 batteries last more cycles. We make our renewable, sustainable Green Energy batteries because they are simply better than anything else, including other green batteries. It can be installed indoors without producing hydrogen gas.
4. Applications: CATL 150Ah Prismatic LiFePO4 Cells are used for solar and winch energy systems, RVs, caravans, backup systems, UPS, flashlight LED emergency lights, engine start batteries, electric bicycle/motorcycle/scooter, golf cart/pushchair, power tools, etc.
MANUFACTURER INTRODUCTION
Features:
1- prismatic aluminum shell lifepo4 cells from CATL
2- Support continuous discharge rate of 1C and charge rate of 1C
3- good cell consistency
4- widely applied for special electric vehicles, energy storage and telecommunication, etc
5- long cycle of 3500+ cycles
Specification
|
Item |
Parameters |
Remark |
|
Nominal voltage |
3.2V |
25±2℃，1C |
|
Nominal capacity |
150Ah |
25±2℃，1C |
|
Operating voltage |
2.5~3.65V |
T>0℃ |
|
Internal resistance |
0.34±0.05mΩ |
Fresh cell, (30~40%SOC)
|
|
Shipment capacity |
60±1Ah |
|
|
Self-discharge rate |
≤3.5% |
25℃, 50%SOC， |
|
Operating temperature range |
Charge: 0~60℃ Discharge: -30~60℃ |
|
|
Standard charge current |
0.5C |
25±2℃ |
|
Max. continuous charge current |
1C |
25±2℃ |
|
Charge voltage |
3.65V |
|
|
Standard discharge current |
75.0A |
25±2℃ |
|
Max. continuous discharge current |
150.0A(1C) |
|
|
Max. pulse discharge current (long pulse) |
300A(2C) |
3 minutes |
|
Max. pulse discharge current (short pulse) |
450.0A(3C) |
T＜50℃ 60S, SOC>40% 10S, SOC<40% |
|
Discharge cut-off voltage |
2.5V 2.0V
|
T>0℃ T≤0℃ |
|
Cycle life |
≥3500 cycles |
80%DOD |
|
Dimension |
200.33*207.2*33.4mm |
|
|
Weight |
2.95±0.3Kg |
|
